Thermal CTP Plate Processor

Features: 1. PVC tank and duralumin body resistant to corrosion. 2. Extra-long developing with stable uniformity, especially adaptive to high-speed photosensitization thermal CTP plates. 3. Overdeveloping gum roller assures no damage to the surface and two sets of wash brushes assures sufficient development. 4. Independent develop cooling system keeps the develop temperature fluctuation within 0.5 dgree Celcius. 5. Accurate automatic anti-oxidation detecting and replenishing system of Superluck CTP plate processor controls developing concentration. 6. Automatic cleaning and recycling. 7. Precise PLC control, processing without any letup. 8. Energy saving and environment friendly. ModelSL-65THSL-85THSL-135THMaterialThermal CTP plateCapacity20­-150 cm/minPlate width (mm)6508501350Min. Plate length(mm)300450450Plate thickness(mm)0.15-0.4Tank content, developer(L)255068Tank content, wash(L)913.520Adjustable temperature, dev0 to 40 degree C. adjustableAdjustable temperature, drynormal temperature to 70 degree C.Water consumption, max6L/min8 L/min12 L/minDiameter of wash brush (mm)50Rotary speed of wash brush80 rpmFilter(um)75Water supplyTap water (min. pressure 1 bar)GummingRoller pressing gummingDiameter of roller60mmDev. replenishment0-1L per plateDev. heating-up rate0.5 degree C. per minuteHorizontal adjustmentAdjustablePower supply380V 3 phases50-60HzPower consumption (kwh)3.53.54.5Voltage fluctuationwithin 10%Gross weight(kg)400500780Net weight(kg)320420650
